A bridge domain for an EPG called "Web Servers" must be created in the Cisco APIC. The configuration must meet these requirements:

1.

Only traffic to known MAC addresses must be allowed to reduce noise.

2.

The multicast traffic must be limited to the ports that are participating in multicast routing.

3.

The endpoints within the bridge domain must be kept in the endpoint table for 20 minutes without any updates.

Which set of steps configures the bridge domain that satisfies the requirements?

A. Switch L2 Unknown Unicast to Flood. Select the default Endpoint Retention Policy and set the Local Endpoint Aging to 20 minutes. Set Multicast Destination Flooding to Flood in Encapsulation.

B. Set L2 Unknown Unicast to Hardware Proxy. Configure L3 Unknown Multicast Flooding to Optimized Flood. Create an Endpoint Retention Policy with a Local Endpoint Aging Interval of 1200 seconds.

C. Multicast Destination Flooding should be set to Flood in BD. Set L3 Unknown Multicast Flooding to Flood. Select the default Endpoint Retention Policy with a Local Endpoint Aging Interval of 1200 seconds.

D. Select the ARP Flooding checkbox. Create an Endpoint Retention Policy with a Remote Endpoint Aging Interval of 20 minutes. Set L3 Unknown Multicast Flooding to Optimized Flooding.

Refer to the exhibit.

An engineer wants to initiate an ICMP ping from Server1 to Server2. The requirement is for the BD1 to enforce ICMP replies that follow the expected path. The packets must be prevented from taking the direct path from Leaf1 to Server1. Which action must be taken on BD1 to meet these requirements?

A. Set L2 Unknown Unicast to Flood.

B. Set L2 Unknown Unicast to Hardware Proxy.

C. Disable Unicast Routing.

D. Enable ARP Flooding.

When does the Cisco ACI leaf learn a source IP or MAC as a remote endpoint?

A. When VXLAN traffic arrives on a leaf fabric port from the spine and outer source IP is in the Layer 3 Out EPG subnet range.

B. When VXLAN traffic arrives on a leaf fabric port from the spine and outer source IP is in the bridge domain subnets range.

C. When VXLAN traffic arrives on a leaf fabric port from the spine and inner source IP is in the Layer 3 Out EPG subnet range.

D. When VXLAN traffic arrives on a leaf fabric port from the spine and inner source IP is in the bridge domain subnets range.

Refer to the exhibit.

An engineer configures the Cisco ACI fabric for VMM integration with ESXi servers that are to be connected to the ACI leaves. The server team requires the network switches to initiate the LACP negotiation as opposed to the servers. The LAG group consists of two 10 Gigabit Ethernet links. The server learn also wants to evenly distribute traffic across all available links. Which two enhanced LAG policies meet these requirements? (Choose two.)

A. LACP Mode: LACP Standby

B. LB Mode: Destination IP Address and TCP/UDP Port

C. LB Mode: Source and Destination MAC Address

D. LB Mode: Source IP Address and TCP/UDP Port

E. LACP Mode: LACP Active

An engineer wants to filter the System Faults page and view only the active faults that are present in the Cisco ACI fabric. Which two lifecycle stages must be selected for filtering? (Choose two.)

A. Raised

B. Retaining

C. Soaking, Clearing

D. Raised, Clearing

E. Soaking
