NS0-520 Online Practice Questions and Answers

Questions 4

You are asked to serve iSCSI LUNs in an existing SVM on your AFF A220 using ONTAP 9.5. You verified that the iSCSI license is configured on your cluster and that the iSCSI protocol is enabled. Referring to the exhibit, what is needed to allow hosts to log into the iSCSI target?

A. Create new LIFs with the iSCSI data protocol.

B. Create new igroups with the host IQNs.

C. Add iSCSI to the data protocol of the existing LIFs.

D. Map LUNs to the igroups.

Browse 234 Q&As
Questions 5

You have a performance critical database application that is running on a FAS9000 controller that uses FC. As shown in the exhibit, volume efficiency is enabled. If you follow the performance recommendation, what are two results to the data in the volume? (Choose two.)

A. The new written data is compressed.

B. The new written data is uncompressed.

C. The existing data is uncompressed.

D. The existing data is compressed.

Browse 234 Q&As
Questions 6

You have a requirement to serve LUNs with under 200 microsecond latency using local server lass memory. You also are required to use a shared SAN.

Using MAX Data as shown in the exhibit, which two LUN access protocols are supported with this solution? (Choose two.)

A. iSCSI

B. FCoE

C. FC

D. NVMe

Browse 234 Q&As
Questions 7

Automatic host-side space management with SCSI T10 thin-provisioned LUNs is achieved by which feature of ONTAP?

A. fractional reserve

B. space allocation

C. space reservation

D. volume auto-grow

Browse 234 Q&As
Questions 8

Click the Exhibit button.

A 4-node cluster was expanded with two news nodes (Nodes 5 and 6). You are now attempting to set up four FC LUNs on the two new nodes that use the ps2 igroup name, although FC ping works. LUNs on the previous four nodes are discoverable, but the four new LUNs on the new controllers are not discoverable.

Referring to the exhibit, what is the problem?

A. The zones between the hosts and LIFs are from node-05 and node-06.

B. Selective LUN Mapping (SLM) is not configured for this HA pair.

C. The portset must be configured to reflect Nodes 5 and 6.

D. Igroup ps2 has the portset configured with the LIFs.

Browse 234 Q&As
Questions 9

You are planning to set up a new SAN with an AFF A300 2-node switchless cluster. Your SAN fabric will consist of Cisco MDS9148s switches. According to NetApp best practices, which two actions would be required to accomplish this task? (Choose two.)

A. Set the switchport speed setting to 16 Gb.

B. Use single initiator, multiple target zoning.

C. Use multiple initiator, single target zoning.

D. Set the switchport speed to auto negotiate.

Browse 234 Q&As
Questions 10

An enterprise customer has both a NetApp FAS8200 4-node cluster and a third-party storage array in a shared SAN environment. The host servers connect to both storage vendors' arrays in the fabric.

Regarding (he hosts in this scenario, what are- two NetApp best practices when performing this task? (Choose two.)

A. Set the default timeout values and storage parameters for the host system.

B. Provide isolation between storage systems using NetApp's multitenancy feature.

C. Always use the same adapter for heterogeneous storage systems.

D. Use separate adapters to connect to each vendors' storage system.

Browse 234 Q&As
Questions 11

When booting your NetApp storage system for the first time the system fails to boot.

What should you do first to address this problem?

A. You turn off your storage system and disk shelves, and then turn on the disk shelves. You then check the quick reference card that came with the disk shelf for information about LED responses.

B. You re-download the boot image to the compact flash card, then reboot the system.

C. You look for a description of the problem on the LCD and console. You then follow the instructions, if provided, on the LCD and console.

D. You verify disk shelf compatibility and check the disk shelf IDs to verify that the disk shelf 1 (for DS14 series) must be connected to your system.

Browse 234 Q&As
Questions 12

Exhibit.

You want to map a LUN to a server.

To which SAN object is the highlighted value in the exhibit added?

A. LUN

B. fabric zone

C. FlexClone

D. igroup

Browse 234 Q&As
Questions 13

Exhibit.

You want to configure a UTA2 port as an FCoE target. Referring to the exhibit, which action must be performed?

A. Configure the port mode as CNA.

B. Configure the port mode as Ethernet.

C. Configure the port type as initiator.

D. Configure the port mode as FC.

Browse 234 Q&As
Questions 14

Exhibit.

You are working on a project to install a new AFF A300 storage array. You use a pair of Nexus 3596 switches for FC connectivity between your VMware ESXi servers and the AFF A300.

Which SAN switch feature must be enabled to accomplish this task?

A. N_Port ID visualization (NP1V)

B. Open Shortest Path First (OSPF)

C. Link Aggregation Control Protocol (LACP)

D. N_Port Visualization (NPV)

Browse 234 Q&As
Questions 15

A customer wants to deploy NVMe/FC along with an existing FC SAN fabric using ONTAP 9.8. In this scenario, which two actions are correct? (choose two)

A. Use existing zoning on fabric switches

B. Enable NVMe/FC on the existing FC SVM

C. Upgrade your FC switches from 16GB to 32GB

D. Create new zoning on fabric switches

Browse 234 Q&As
Questions 16

During maintenance of an AFF A250 node, you want to move the SAN LIFs that are members of a port set. In this scenario, which two statements are true? (choose two)

A. You must disable SLM for the node that hosts the LIF

B. You need to disable the zoning of the LIF WWPN

C. The LIF must be removed from the port set

D. You must take the SAN LIF offline

Browse 234 Q&As
Questions 17

You created a LUN in a new volume on your Netapp ONTAP cluster. You enabled the default snapshot schedule and enabled snapshot autodelete on the volume. In this scenario, in which three situations does the snapshot autodelete feature automatically delete snapshot copies in the volume? (choose three)

A. The snapshot reserve space is nearly full

B. The LUN is nearly full

C. The overwrite reserve space is full

D. The volume is nearly full

E. The aggregate is nearly full

Browse 234 Q&As
Questions 18

What are two considerations when creating a physical reference drawing for adding an ASA AFF A700 system to your existing FC SAN environment? (Choose two)

A. available cooling

B. Hardware Compatibility

C. available rack space

D. switch connectivity

Browse 234 Q&As
