Click the Exhibit button.
Referring to the exhibit, which statement about the IS-IS interface is true?
A. The ge-0/0/0.0 interface will act as an L1/L2 interface
B. The ge-0/0/0.0 interface will act as an L2 interface only
C. The ge-0/0/0.0 interface will act as an L1 interface only
D. The ge-0/0/0.0 interface will not be assigned to a level
Click the Exhibit button.
Referring to the exhibit, which statement is true?
A. The router will attempt to signal the LSP along the IGP shortest path to 192.168.100.1
B. The router will prune links with insufficient bandwidth from the path before beginning the signaling process
C. The router will analyze the traffic engineering database to determine the best path through the network
D. The router will precalculate a valid path through the network for LSP r1-to-r3
Click the Exhibit button.
Referring to the exhibit, the GRE tunnel between R-1 and R-2 allows connectivity between User-1 and Server-1. When User-1 communicates with Server-2 with packets that are 1472 bytes in size, no packet fragmentation occurs. User-1 can communicate with Server-1 with packets that are up to 1448 bytes in size with no packet fragmentation. However, if the packet size is larger than 1448 bytes, packet fragmentation occurs.
Why is the packet fragmentation occurring between User-1 and Server-1 in this scenario?
A. The GRE header adds 20 bytes to the packet
B. The GRE header adds 24 bytes to the packet
C. The IP header adds 20 bytes to the packet
D. The IP header adds 24 bytes to the packet
Which action would you use to connect two virtual switches that are configured on the same router?
A. Create a VRF routing instance
B. Create a forwarding routing instance
C. Connect the virtual switches with a cable
D. Configure an irb interface
Click the Exhibit button.
Referring to the exhibit, which two statements are true? (Choose two.)
A. The configuration is for an external BGP session
B. The local-address statement is required for the BGP session to establish correctly
C. The multi-hop statement is required for the BGP session to establish correctly
D. The configuration is for an internal BGP session
What is the correct description of an Area Border Router (ABR)?
A. An ABR is an OSPF router with links in two areas, connecting OSPF areas to the backbone
B. An ABR is an OSPF router that injects routing information from outside the OSPF AS
C. An ABR is an OSPF router with at least one link in a Layer 2 area
D. An ABR is an OSPF router with all of its links within an area
Click the Exhibit button.
You are configuring an IBGP group. When you commit your configuration, you receive the error shown in the exhibit.
Which additional configuration parameter must you add to your configuration?
A. multipath
B. type external
C. type internal
D. export
Click the Exhibit button.
Referring to the exhibit, which statement is correct?
A. Routes from 10.1.1.1 are more preferred than routes from 10.2.2.2
B. Routes from 10.2.2.2 are less preferred than the default local preference
C. Routes from 10.3.3.3 are more preferred than the default local preference
D. Routes from 10.2.2.2 are less preferred than routes from 10.3.3.3
You must establish an MPLS LSP between two locations. You are required to ensure that the LSP traverses specific routers within the network.
Which solution is correct in this scenario?
A. Enable traffic engineering within RSVP and enable the Fast Reroute feature
B. Implement RSVP and define the explicit route the LSP must follow
C. Implement LDP and define the explicit route the LSP must follow
D. Enable traffic engineering within LDP and define the explicit route the LSP must follow
To which multicast address is a VRRP advertisement packet sent?
A. 224.0.0.6
B. 224.0.0.18
C. 224.0.0.22
D. 224.0.0.13
Click the Exhibit button.
Referring to the exhibit, which statement is correct?
A. R2 will be the designated router
B. R3 will not participate in the election process
C. R1 will not participate in the election process
D. R4 will be the designated router
You have two MX Series devices connected together and configured for Layer 2 operations. The interface that connects the two routers must carry tagged and untagged traffic.
Which approach would meet this objective?
A. Configure the interfaces as access ports with the native VLAN option
B. Configure the interfaces as trunk ports with the native VLAN option
C. Configure the interfaces as access ports with the voice VLAN option
D. Configure the interfaces as trunk ports with the voice VLAN option
Which statement is true when using MVRP on MX Series devices?
A. MVRP works with MSTP and RSTP, but not VSTP
B. MVRP works with RSTP and VSTP, but not MSTP
C. MVRP works with MSTP and VSTP, but not RSTP
D. MVRP does not work with MSTP, RSTP, and VSTP
What is the purpose of STP BPDUs?
A. to exchange MAC addresses
B. to determine the least cost path
C. to determine the root-alternate port
D. to determine the root bridge
Which of following two statements are true for GRE tunneling? (Choose two.)
A. GRE tunnels are stateful by default
B. GRE tunnels support multiple logical units per interface
C. GRE tunnels support only one logical unit per interface
D. GRE tunnel endpoints must have a valid route to the remote endpoint
