Core# configure terminal Core(config)# vrf Green Core(config-vrf)# exit Core(config)# Core(config)# interface vlan 50 Core(config-if-vlan)# ?
Given the configuration on the CORE switch shown above, what command would follow to assign the switched virtual interface (SVI) vlan 50 to the VRF created?
A. Core(config-if-vlan)# vrf attach Green
B. Core(config-if-vlan)# ip vpn-instance Green
C. Core(config-if-vlan)# ip vrf forwarding Green
D. Core(config-if-vlan)# routing-context Green vrf
ServiceOS login: admin
SVOS> password
Enter password: ********
Confirm password: ********
The login password to access an Aruba AOS-CX was lost. After connecting to the switch console port, a reboot is performed and the Service OS console is accessed as shown above.
What is the default password that is required for the admin account while under the Service OS console?
A. No password is set for this account.
B. "password"
C. "forgetme!"
D. The same login password that has lost originally.
The section in blue can be ignored.
SW1(config)# interface 1/1/1-1/1/2 SW1(config-if-<1/1/1-1/1/2)# vlan access 2 SW1(config-if-<1/1/1-1/1/2)# exit SW1(config)# interface 1/1/11-1/1/17 SW1(config-if-<1/1/11-1/1/17)# vlan access 17 SW1(config-if-<1/1/11-1/1/17)# exit
After completing the above commands, what is the expected output of show vlan with no other vlan commanded having been added?
A. Option A
B. Option B
C. Option C
D. Option D
Your customer has 349 users in a two-story building.
What are two benefits of a 2-Tier design? (Choose two.)
A. Layer 2 and Layer 3 protocols run close to the endpoints to better implement ACL and QoS policy at the edge.
B. Improved performance by offloading processing from the Access layer to the Core.
C. Use of layer 2 switches at the access layer can process and route traffic from attached APs.
D. Support for WAN/MPLS, Internet, and Data Center directly on the Collapsed core.
E. Provides a more cost effective solution given that no additional switches are required for a third tier.
Refer to the exhibit
Which command on Access-2 port 1/1/4 will enable connectivity between PC-1 and Server-1 without any routing enabled in the network?
A. Access-2 (config-if-1/1/4)# vlan access 1, 10, 20, 255
B. Access-2 (config-if-1/1/4)# vlan access 20
C. Access-2 (config-if-1/1/4)# vlan 20 untag 1/1/4
D. Access-2 (config-if-1/1/4)# vlan trunk allow 1, 10, 255
Refer to the exhibit.
LLDP
The command show LLDP neighbor-info gets typed into Access-1. All switches are Aruba OS-CX switches.
What is the output of this command?
A. Option A
B. Option B
C. Option C
D. Option D
Interface 1/1/1 is up Admin state is up Link transitions: 1 Description: TO_PC-1 Hardware: Ethernet, MAC Address: 00:11:22:33:44:55 MTU 1500 Type 1GbT Full-duplex qos trust none Speed 1000 Mb/s Auto-negotiation is on Flow-control: off Error-control: off MDI mode: MDIX VLAN Mode: access Access VLAN: 1111
Which command will produce the above output?
A. show interface vlan 1111
B. show interface 1/1/1
C. show interface gigabit 1/1/1
D. show vlan 1111
Refer to the exhibit
What is true regarding VLAN 50 according to the diagram above?
A. VLAN 50 is part of a switched virtual interface (SVI) that was never routed causing it to be down.
B. Since VLAN 50 has not been assigned to any enabled physical port, the status is down.
C. VLAN 50 is assigned only to Trunk ports which is why no ports are listed under interfaces.
D. VLAN 50 was never added to the vlan-database and therefore is in a down state.
Which two types of routes can be found in the IP routing table of an Aruba AOS-CX switch? (Choose two.)
A. Local
B. EIGRP
C. BGP
D. ISIS
E. RIPng
Aruba Access Points tunnel traffic in a campus to the Mobility Controller using which protocol?
A. Control and Provisioning of Wireless Access Points (CAPWAP)
B. Generic Routing Encapsulation (GRE)
C. Lightweight Access Point Protocol (LWAPP)
D. Process Application Programming Interface (PAPI)
What is the login and password combination is used when first configuring an Aruba OS-CX switch from factory defaults?
A. Login admin and password admin.
B. Login admin and password field empty.
C. Login admin and password forgetme!.
D. Login admin and password password.
Refer to the exhibit.
What commands will successfully enable the SVI for vlan 100 on interface 1/1/1 to produce the results displayed in the command show ip interface brief in the exhibit below?
A. Access-1(config)# interface 1/1/1Access-1(config-if)# routingAccess-1(config-if)# interface vlan 100Access-1(config-if-vlan)# ip address 10.1.1.1/24
B. Access-1(config)# interface 1/1/1Access-1(config-if)# vlan trunk permit vlan 100Access-1(config-if)# interface vlan 100Access-1(config-if-vlan)# ip address static 10.1.1.1/24
C. Access-1(config)# interface vlan 100Access-1(config-if-vlan)# ip address 10.1.1.1/24
D. Access-1(config-if)# vlan 100Access-1(config-vlan)# ip address 10.1.1.1/24
Refer to the exhibit.
What is the correct binary conversion of the last two hexadecimal characters of the physical address?
A. 1101 1000
B. 1110 1101
C. 1001 1111 0101 0011
D. 1000 1101 1110 1101
With what other technology does Half Duplex communication closely match?
A. a pair of fiber optic strands allowing transmit on one and receive on the other at the same time
B. a mobile phone call
C. point-to-point connections between two switches allowing concurrent transmit and receive
D. CB radio using push-to-talk
Refer to the exhibit.
What VSF command produces the above output?
A. show vsf member
B. show vsf link
C. show vsf topology
D. show vsf detail
