HP2-Z37 Online Practice Questions and Answers

An HP Provision switch has port A1 connected to port g1/0/1 of an HP Comware switch. The ProVision port has the following configuration: vlan 1 untag A1 vlan 10 tag A1 vlan 20 tag A1

Which Comware configuration will allow the three VLANs to successfully pass traffic between the two switches?

A. interface g1/0/1port link-type trunkport trunk permit vlan 1 10 20

B. interface g1/0/1 port trunk encapsulation dot1qport trunk native vlan 1port trunk permit vlan 1 10 20

C. interface g1/0/1 port trunkport trunkpermit auto-vlan

D. interface g1/0/1 port trunkport trunkpermit auto-vlan

Which command can a network administrator execute on an HP Comware switch to manage configuration files?

A. delete

B. startup-default

C. write file

D. write memory

An HP Comware switch should send messages to an SNMP server when various events occur. What is one step in the configuration of this feature?

A. Enable SSH on the switch, and create a user account to match settings on the SNMP server.

B. Set the SNMPv2 read-write community string to match the string on the SNMP server.

C. Enable logging to the console globally.

D. Specify an SNMP trap server with the SNMP server IP address and community string.

How does a switch treat a link aggregation?

A. The switch treats each interface within the interface as a separate entity for MAC address learning; it also assigns an individual spanning tree port role to each interface.

B. The switch treats the link aggregation as one logical link for spanning tree, but it learns MAC addresses separately on each individual interface within the aggregation.

C. The switch treats the link aggregation as one logical link. It assigns one spanning tree port role to the link aggregation, and it learns MAC addresses on the aggregation.

D. The switch treats the link aggregation as one logical link for MAC learning, but it assigns an individual spanning tree port role to each interface within the aggregation.

What is the maximum number of active links supported between a device and HP ProVision switches when distributed trunking is used to connect the device to the ProVision switches?

A. Two

B. Four

C. Six

D. Eight

A network administrator enters this command on an HP Comware switch:

save

In interactive mode, the administrator is prompted to save to a file named config.cfg and confirms the save. What is the effect of these actions?

A. The current configuration is saved to config.cfg on a TFTP server but is not used for the startup-config.

B. The startup-config, rather than the correct configuration, is saved to config.cfg on a TFTP server.

C. The current configuration is saved to config.cfg in the flash but is not used for the startup-config.

D. The current configuration is saved to config.cfg in the flash and is used for the startup- config.

When configuring Multiple Spanning Tree Protocol (MSTP), how should VLANs be separated to perform load balancing?

A. placed into separate instances

B. configured with different priority values

C. never configured with more than one VLAN per instance

D. placed into separate regions

Which statement is true about the default configuration on an HP ProVision switch?

A. Spanning tree is disabled.

B. LACP is used when a BAGG interface is created.

C. IRF is enabled.

D. RSTP is the default spanning tree mode.

What is one reason to access the extended boot menu on an HP Cornware switch?

A. To access the switch CLI when you have forgotten the password

B. To set up the switch to be managed by HP Intelligent Management Center (IMC).

C. To configure the switch initial IP address settings

D. To configure the switch to implement Intelligent Resilient Framework (IRF)

An HP switch learns identical valid routes with different protocols. How does the switch choose which route to add to its IP routing table?

A. It adds the route with the highest administrative distance, or route preference.

B. It adds the route with the highest cost.

C. It adds the route with the lowest cost.

D. It adds the route with the lowest administrative distance, or route preference.

Which HP solution delivers automated virtual machine orchestrator, automatic synchronization of network connectivity information, and visibility to performance of wired and wireless users?

A. Unified Wired-WLAN modules and switches

B. Intelligent Management Center (IMC)

C. Virtual Connect FlexFabric

D. Intelligent Resilient Framework

Refer to the Exhibit.

A network administrator needs to configure DHCP on SwitchA. Assume that SwitchA is an HPE Comware switch and is using the default settings for DHCP. The administrator configures the following information:

The administrator then has the DHCP client try to acquire addressing information, but the process fails. What should the administrator do to solve this problem?

A. Execute the routing command on SwitchA.

B. Execute the dhcp enable command on SwitchA.

C. Configure DHCP relay on SwitchB.

D. Enable DHCP Snooping on SwitchA.

When adding a new member to an existing IRF domain, which of the following must you perform first?

A. Define the IRF priority.

B. Create the IRF logical port.

C. Define the IRF domain name.

D. Define the IRF member number.

Which privilege level would a network administrator use to configure an HP ProVision switch?

A. Super

B. User

C. Manager

D. Administrator

A network administrator plans to execute show commands as well as make conjuration changes. Which HP ProVision privilege role must be assigned to an account for the administrator to do this?

A. Operator

B. Administrator

C. Superuser

D. Manager
