Correct Answer: A

The EMC RecoverPoint family provides cost-effective, local continuous data protection (CDP), continuous remote replication (CRR), and continuous local and remote replication (CLR) that allows for any-point-intime data recovery and a new "snap and replicate" mechanism for local and remote replication (XRP).

Splitter-based replication, using VPLEX RecoverPoint splitter-based replication provides synchronous replication, continuous replication with fine recovery granularity (journal based), and replication for active-active datacenters.

References: Introduction to the EMC XtremIO STORAGE ARRAY (April 2015), page 52

Correct Answer: C

DIFF protocol - A vendor specific SCSI command which RecoverPoint uses to query XtremIO with in order

to obtain a bitmap of changes between two snapshot sets.

RecoverPoint uses the output of DIFF command to read the actual data and transfer it to the target side.

References: EMC RECOVERPOINT REPLICATION OF XTREMIO, Understanding the essentials of

RecoverPoint Snap-based replication for XtremIO, page 9 https://www.emc.com/collateral/white-papers/

h14296-wp-recoverpoint-replication-of-xtremio.pdf

Correct Answer: C

Oracle Database performs I/O on data files in multiples of the database block size (db_block_size), which is 8KB by default. The default Oracle Database block size is optimal on XtremIO. XtremIO supports larger block sizes as well. In the case of multiblock I/O (e.g., table/index scans with access method full), one should tune the Oracle Database initialization parameter db_file_multiblock_read_count to limit the requests to 128KB. Therefore, the formula for db_file_multiblock_read_count is: db_file_multiblock_read_count = 128KB / db_block_size

In our case the block size is 1 MB, so the formula db_file_multiblock_read_count is 1 MB/ 8KB = 1024/8 = 128

References: https://www.emc.com/collateral/white-papers/h13497-oracle-best-practices-xtremio-wp.pdf, page 21

Correct Answer: B

XtremIO's snapshot technology is implemented by leveraging the content-aware capabilities of the system (Inline Data Reduction), optimized for SSD media, with a unique metadata tree structure.

XtremIO leverages a proprietary flash-optimized data protection algorithm (XtremIO Data Protection or XDP), which provides performance that is superior to any existing RAID algorithm.

References: Introduction to the EMC XtremIO STORAGE ARRAY (April 2015), page 33

Correct Answer: D

Incorrect Answers:

B: OpenStack Cinder features include:

Clone a volume: With inline deduplication, compression and thin provisioning.

C, D: EMC XtremIO OpenStack Block Storage driver, supported operations: Create, delete, clone, attach, and detach volumes Create and delete volume snapshots Create a volume from a snapshot Copy an image to a volume Copy a volume to an image Extend a volume

References: https://docs.openstack.org/juno/config-reference/content/XtremIO-cinder-driver.html https://www.emc.com/collateral/data-sheet/h13287-ds-xtremio-openstack.pdf
