DES-4122 Online Practice Questions and Answers

DRAG DROP

Match each status LED indicator on the Dell EMC 14G PowerEdge server with its corresponding condition.

Select and Place:

A technician is creating a virtual disk in the iDRAC (2x 4 TB NL-SAS in RAID 1) to install Windows 2016 They manually boot to the OS installation media without using the Lifecycle Controller OS Deployment wizard Only the first 2048 GB on the virtual disk can be partitioned

How should the technician obtain access to the remaining 2 TB (approximately) of storage?

A. Use the Lifecycle Controller OS Deployment Wizard to deploy the OS on this server

B. Delete the 4 TB virtual disk and create a virtual (boot) disk no larger than 2048 GB

C. Upgrade to a newer version of the operating system

D. Use F2 to go into the BIOS, change the BIOS boot mode to UEFI, and try again

Dell EMC PowerEdge 14G servers support which technology?

A. Quicksync 1.0

B. Intel Boot Guard

C. AMD GuardMI

D. iDRAC8

A Dell EMC PowerEdge 14G server uses Intel OPTANE DC Persistent Memory in App Direct mode. What is the minimum size DIMM supported for this type of memory?

A. 64 GB

B. 128 GB

C. 256 GB

D. 512 GB

A technician needs to change the iDRAC password on a Dell EMC PowerEdge 14G server in a lights-out datacenter. The be rebooted because it is in production. The iDRAC is configured with the default credentials How could the technician change the iDRAC password?

A. SupportAssist Enterprise

B. iDRAC Web GUI

C. OpenManage Server Administrator

D. Virtual Console; press F2 after rebooting system

A Dell EMC PowerEdge server logs the following CPU Machine Check error CPU1 IERR What action might solve the problem?

A. Remove flea power

B. Update the Intel driver

C. Reseat the IDSDM

D. Swap the PERC controller

What can be done using in-band management?

A. Agentless discovery

B. Firmware and driver updates

C. Network bandwidth optimization

D. Remote access

When does a customer require the Service Tag of the Dell EMC PowerEdge server?

A. First time logging in to iDRAC

B. First time accessing the BIOS

C. Activating the OS

D. Obtaining warranty information

You must configure a BOSS card with 2 x 120GB drives for a Dell EMC PowerEdge server. What is the only supported mode?

A. RAID 0

B. RAID 5

C. RAID 1

D. Non-RAID Mirroring

A Dell EMC PowerEdge server has been updated with an LCC and iDRAC DUP to the latest firmware when performing a firmware rollback?

A. Both the iDRAC and the LCC can be rolled back

B. The LCC can be rolled back; the iDRAC cannot be rolled back

C. The iDRAC can be rolled back; the LCC cannot be rolled back

D. The iDRAC cannot be rolled back and the LCC cannot be rolled back

Which rear disk drive option is available in a Dell EMC PowerEdge R740xd server?

A. 4x 3.5" drives

B. 2x3.5" drives

C. 8x2 5" drives

D. 6x2 5" drives

What is a characteristic of out-of-band management?

A. Dedicated device

B. Agent based

C. Less secure

D. Dependent upon OS

What is required to use the iSM Automatic System Recovery feature?

A. Server Administrator installed

B. OS watchdog timer disabled

C. Server Administrator not installed

D. OS watchdog timer enabled

Which processor configuration is used by the Dell EMC PowerEdge R740 server?

A. 4 socket AMD

B. 2 socket AMD

C. 2 socket Intel

D. 4 socket Intel

What are key values related to systems management when deploying OpenManage Enterprise wit Dell EMC PowerEdge servers?

A. Automate Basic Hardware Element Management Agent-free Management Simple and effective

B. Simplify Basic Hardware Element Management Agent-free Management

Fee-based license

C. Simplify Fee-based license Agent-free Management Secure

D. Simplify Unify Automate Secure
