The __________ field indicates whether IP forwarding is enabled globally when the show ipconfig command is entered.
In order for a static route to not forward broadcast or multicast traffic the __________ keyword must be used when it is configured.
Up to this number of VLANs can be tagged on a single link between Extreme Networks switches.
An Ethernet broadcast domain is equivalent to a __________ within the switch.
SNMP access to ExtremeWare can be limited by the following methods:
A. Use an access list
B. Use an access profile
C. Use the disable snmp access command
D. None of these
How can you tell which ports are disabled?
A. Flashing amber light
B. Flashing green light
C. Flashing red light
D. None of these
OSPF area 0.0.0.0 is connected to area 1.1.1.1. Stub area 2.2.2.2 is connected to area 1.1.1.1. Area 2.2.2.2 routers show only directly connected networks in their IP route tables. What must you do to resolve this situation?
A. Create a virtual link between areas 0.0.0.0 and 2.2.2.2.
B. Create a virtual link between areas 2.2.2.2 and 0.0.0.0.
C. Create a virtual link between areas 1.1.1.1 and 2.2.2.2.
D. Create a virtual link between areas 1.1.1.1 and 0.0.0.0.
How will you change the CLI prompt from the default display to NA-CHI-B6-F2-001?
A. config snmp syslocation NA-CHI-B6-F2-001
B. config snmp sysname NA-CHI-B6-F2-001
C. config cli prompt NA-CHI-B6-F2-001
D. config cli display NA-CHI-B6-F2-001
Which of these are valid load sharing algorithms?
A. Port-based
B. MAC-based
C. Ratio-based
D. All of these.
Equal cost multi-path routing (ECMP) can be used with which of the following?
A. RIP
B. OSPF
C. BGP
D. Static routes
Exhibit: Given the following diagram, which command would you use to send the switch configuration from the switch to the TFTP server?
A. download config 192.168.0.1
B. upload config 192.168.0.254
C. download config 192.168.0.254
D. upload config 192.168.0.1
All versions of ExtremeWare are compatible with all ESRP master-election algorithms.
A. True
B. False
What is the default RIP route advertisement timer value?
A. 30 seconds
B. 60 seconds
C. 90 seconds
D. 120 seconds
Which command would you use to add a VLAN to STPD s0?
A. config stpd s0 add vlan
B. config s0 stpd add vlan
C. config stpd add s0 vlan
D. config s0 add stpd vlan
In unicast IP routing, all forwarding decisions are based on the ______ of each packet.
A. destination MAC address
B. source IP address
C. source MAC address
D. destination IP address
