71200X Online Practice Questions and Answers

How do calls access the ARS routing tables?

A. By using the Toll Analysis table

B. By using the Public Unknown Numbering table

C. By using Dial Plan Parameters

D. By using the Feature Access Code

Which list command can trace the traffic entering and leaving Communication Manager on a specific trunk?

A. list trace vdn

B. list trace tac

C. list trace station

D. list trace ras

To ensure that your Survivable Communication Manager (CM) is updated daily with the latest translation date from your Main CM, which form should you update?

A. system-parameters maintenance

B. system-parameters customer-options

C. system-parameters Ip-options

D. system-parameters features

What are two main roles of Avaya Aura System Manager? (Choose two.)

A. User Profile Management

B. RTCP Network Monitoring

C. Quality of Service Management

D. Centralized Product Management

E. Network Switching Management

Which two options represent a function of a Digital Signal Processor (DSP)? (Choose two.)

A. Convert from Signaling to Audio.

B. Convert between two different Codecs.

C. Analyze and route SIP Signaling.

D. Convert between Analogue speech and Digital Audio.

E. Perform Gatekeeper functions.

When a simple SIP telephone without CM Features registers to the Avaya Aura Core, which IP address will it register to?

A. Avaya Aura System Manager IP Address

B. Avaya Aura Session Manager Management IP Address

C. Avaya Aura Session Manager SM100 IP Address

D. Avaya Aura Communication Manager IP Address

What can be done from the Session Manager Dashboard in Avaya Aura System Manager?

A. Select each administered SM tor each SIP-User

B. Get information status and health summary of each administered SM

C. Administer (create new user) each administered SM

D. Import data (synchronized) from each administered the SM

You need to convert a one X?Communicator from H.323 mode to SIP. You have accessed the settings

menu and chocked the SIP radio button. You need to enter the SIP domain, but the SIP domain field is not

being displayed.

Which action needs to happen?

A. SIP needs to be enabled In the Preferences menu.

B. No action since this version of one X?Communicator only supports H.323.

C. The SIP TLS certificate needs to be installed.

D. The softphone needs to restart to offer the correct menu.

Ping attempts are failing to the SM100 IP address of a newly deployed SM, and you discover the problem is due to an incorrectly configured SM100 default gateway router address. Which action would you take to correct this configuration?

A. Execute runsmconsole.

B. Use Avaya Aura System Manager (SMGR) web GUI to edit the SM Instance under SM Administration.

C. Execute SMnetSetup.

D. Use Avaya Aura System Manager (SMGR) web GUI to edit the SIP Entity screen under Routing.

Solution Deployment Manager (SDM) allows you to install and administer applications on Host ESXI

servers.

Which three statements are true? (Choose three.)

A. SDM can be installed on Macintosh.

B. SDM can be downloaded as an Android application on a tablet.

C. SDM can be installed as client on your laptop.

D. SDM comes as part of Avaya Aura System Manger 7.x.

E. SDM can install Avaya Aura Session Manager (SM) on Avaya Virtualized Platform.

In Avaya Aura 7.x, where are the listening ports defined to allow Avaya Aura Session Manager (SM) to listen for User Agent (UA) registrations?

A. Communication Profile

B. SM Firewall

C. SIP Entity

D. SM Administration

Which three products comprise the Collaboration Bundle? (Choose three.)

A. Avaya Session Border Controller for Enterprise (SBCE).

B. Avaya Aura Media Server (AAMS)

C. Avaya Scopia Solution

D. Avaya Aura Conferencing (AAC)

E. Avaya Aura Application Enablement Services

Which three functions are provided by Avaya Aura Media Server? (Choose three.)

A. Provides other Avaya Aura Components with DSP Resources

B. Transcoding

C. Announcements

D. Conversion between TDM and VoIP E. Call Routing

Which Avaya Aura Communication Manager (CM) Reset Level typically takes less than 10 seconds, and preserves stable calls as well as Error and Alarm logs?

A. Reset System 4

B. Reset System 3

C. Reset System 2

D. Reset System 1

How do you verify that the Avaya Aura Session Manager (SM) replica NODE is synchronized?

A. Register an Avaya SIP Telephone (AST) and check to see its feature buttons.

B. Check the status of the Replication group/Replication Nodes.

C. Check in the Replica Group for a green ''Session Manager OK''.

D. PuTTY to Avaya Aura Session Management (SM) and run statusapp, and then check that all processes are started.
