301A Online Practice Questions and Answers

Refer to the exhibit.

An LTM Specialist has multiple SNAT and virtual server objects configured as in the bigip.conf shown. The LTM Specialist tests a connection from a client with. IP 172.163.31.11 to 192.168.0.100:80. Which two objects will show an increase in Local Traffic statistics connections?

A. VS_AandSNAT_B

B. VS_BandSNAT_B

C. VS_ B and SNAT A

D. VS_A and SNAT A

A BIG IP system load balances connections to a web application. A TCP-based Denial of Service attack

against the web application is occurring, which has caused very high memory utilization on the LTM device

due to stale TCP connections.

Which TCP profile option should be used to reduce memory utilization?

A. Idle timeout

B. Reset on timeout

C. Slow Start

D. Multipath TCP

An unwanted IP address tries to connect to the configuration utility via Self IP An LTM Specialist needs to block the attempts based on the IP address. How should the ITM Specialist block the attempts without affecting other users?

A. SSH IP allow list

B. Port lockdown

C. Device trust

D. Packet filter

In an iApp, which configuration protects against accidental changes to an application Services configuration?

A. Components

B. Strict Updates

C. Name

D. Template

Refer to the following iRule:

What is a complete list of profiles that must be applied to the virtual server for this iRule?

A. Fast L4, HTTP

B. TCP, HTTP

C. TCP, HTTP, Client SSL

D. Fast L4 , HTTP, Stream

A node is assigned two monitors as seen in this configuration.

What is the status of a member that runs on that node and listens on port 443?

A. UNKNOWN

B. UNAVAILABLE

C. DOWN

D. UP

A virtual server configuration for traffic destined to a server is as shown:

HTTP traffic is destined to the 10 10.20.1 server from the source Based on precedence, which virtual server accepts this traffic?

A. MyvS1

B. MyVS2

C. MyVS3

D. MyVS4

An HA pair of LTM devices that load balance multiple HTTPS applications utilizes highly customized RAM Cache and compression profiles on each virtual server. The LTM Specialist who is administering the HA pair regularly observes entines in the log similar to the following: tmm tmm I708S1 011e0002.4. sweeper_update: aggressive mode activated (117504/138240 pages) No DoS attacks arc occurring. No user problems have been reported. Which step should the LTM Specialist take to help mitigate the issue?

A. change the Adaptive Reaping High watermark

B. change the Adaptive Reaping Low watermark

C. allocate less memory to the RAM cache feature

D. use a OneConnect profile

An LTM Specialist needs to assign a health monitor to a pool with two pool members 10.10.10 101 and

10.10.10.102 Both pool members are listening on port 8080 with TCP. The health of the application depends on the health of an another server (10 10 10 100) that runs port 9080 with TCP. Which two custom TCP monitors should be selected as the pool's health monitors' (Choose two)

A. a custom TCP monitor that works on port 9080 with 10.10.10.100 as alias address

B. a custom TCP monitor that works on port 9080,

C. a custom TCP monitor that works on port 8080

D. a custom TCP monitor that works on port 9080 with 10,10.10.101 as alias address

E. a custom TCP monitor that works on port 8080 with 10.10.10.101 as alias address

F. a custom TCP monitor that works on port 8080 with 10.10.10.102 is alias address

Refer to the exhibit.

The LTM devices LTM3 and LTM2 have four Traffic Groups defined with approximately the sar of failover objects defined in each group.

-

Traffic Groups A and C have Default Device set to LTM1

-

Traffic Groups Band D have Default Device set to LTM2.

-

Traffic Groups B and C do NOT have Auto Failback enabled. Traffic Groups A and D have Auto Failback

enabled with a timeout value of 60 seconds.

-

Traffic Groups A and D have Auto Fallback enabled with a timeout value of 60 seconds. Both LTM

devices are healthy and able to pass traffic for any Traffic Group. LTM1 loses connectivity on interface 1.4.

The LTM Specialists notified 60 seconds after the interface goes down.

What is the state of the Traffic Groups on each LTM device?

A.

LTM1: Traffic Group C LTM2: Traffic Groups A, B, and 0

B.

LTM1: No Traffic Groups LTM2: Traffic Groups A, B. C, and D

C.

LTM1: Traffic Groups A, B, C, and D LTM2: No Traffic Groups

D.

LTM1: Traffic Groups B and C LTM2: Traffic Groups A and 0

What should an LTM Specialist configure on an LTM device to send AVR notification emails?

A. Email notification to be sent via iControl from the LTM device

B. Syslog on the LTM device to send to an SMTP server

C. Custom SNMP traps on the LTM device for AVR notifications

D. Email notification to be sent via SMTP from the LTM device

An LTM Specialist needs to upgrade all guests on a Viprion eight CMP guests. What is the maximum number of guests that the LTM Specialist should upgrade at once?

A. Eight

B. One

C. TWO

D. Four

An LTM Specialist is configuring a client profile to offload processing a new application Company policy

requires that clients can resume session for up to 30 minutes, but must renegotiate a new session after

that.

Which setting should the LTM Specialist change to satisfy this requirement?

A. Renegotiate Max Record Delay

B. Renegotiation period

C. Cache size

D. Cache timeout

An LTM Specialist needs to use the tmsh command to create a pool named http_pool with member

10.10.101:80

on an LTM device. Which expression should the LTM Specialist use?

A.

# tmsh create pool http_pool members {10.10.10.101:80}

B.

# tmsh create pool http_pool members add {10.10.10.101:80}

C.

# tmsh create it pool http_pool members {10.10.10.101:80}

D.

# tmsh create itm pool http_pool member {10.10.10.101:80}

An LTM device is configure with the wildcard virtual servers displayed below. A client connection is made to 172.24.31.14:443.

A. VS_172_24_1_WILDCARD

B. VS_HTTP_WILDCARD

C. VS_172_24_WILDCARD

D. VS_HTTPS_WILDCARD
