DRAG DROP
Drag and drop the boot issues from the left onto the correct solutions on the right.
Select and Place:
Which component is initially responsible for loading the kickstart image on Cisco MDS Switches?
A. ROMMON
B. BIOS
C. NX-OS
D. BASH
After user account attributes are modified in Cisco NX-OS, when do changes to the user's session attributes take effect?
A. immediately
B. at the scheduled time
C. when the user logs out of a session
D. when the user creates a new session
A storage network engineer is implementing disk-array data replication between two SAN environments in two different data centers not connected via Fibre Channel. Which SAN switch feature must be implemented?
A. FCIP
B. zoning merge over LAN
C. VSAN scoping
D. IVR
Which result occurs if a device alias is renamed and then the original device alias name is used in an add command in the same session?
A. Both commands execute successfully.
B. The device alias is renamed and the add command is moved to the rejected list.
C. Both commands are moved to the rejected list.
D. The rename command is moved to the rejected list and the add command executes successfully.
Which configuration is always required when running the setup utility on a Cisco MDS 9000 Series Switch?
A. administrator password
B. management IP address
C. active NTP server
D. active default gateway
Which port mode is used on an NPV device to connect to an NPIV core switch?
A. E
B. F
C. N
D. NP
A storage administrator is enabling DH-CHAP for the first time on a Fibre Channel fabric. Which condition must the administrator consider while configuring this feature?
A. NTP must be configured on all devices or the configuration fails.
B. The MD5 hash must be used if TACACS+ or RADIUS authentication for FCSP is enabled.
C. All switches on the fabric must be configured for the same password.
D. Enabling DH-CHAP protocol feature is unsupported on FCIP interfaces.
Refer to the exhibit.
What is the result of the configuration?
A. No-drop CoS values are advertised by the DCBX.
B. LFC is prioritized over PFC on Ethernet 1/10.
C. PFC operates on Ethernet 1/10 regardless of the capability of the peer.
D. PFC fails to operate properly unless LFC is disabled on Ethernet 1/10.
Which configuration is needed to enable manual ESP mode for Fibre Channel TrustSec on Cisco MDS switches?
A. MDS(config)# interface fc 1/1 MDS(config-if)# fcsp esp manual
B. MDS(config)# fcsp esp manual
C. MDS(config)# interface fc 1/1 MDS(config-if)# fcsp mode gcm MDS(config-if-fcsp)# fcsp esp manual
D. MDS(config)# interface fc 1/1 MDS(config-if)# fcsp esp manual MDS(config-if-fcsp)# mode gcm
What does an unlicensed DCNM SAN fail to display?
A. Fibre Channel, FCoE, and iSCSI topologies
B. events and fault management
C. historical performance monitoring
D. real-time performance monitoring
A storage engineer is troubleshooting a Cisco MDS switch upgrade issue. What prevents the completion of a non-disruptive upgrade?
A. The Fibre Channel host initiator is connected.
B. The Fibre Channel storage target is connected.
C. The Cisco Fabric Services operation in progress.
D. The Fibre Channel and FCoE storage targets are connected.
Refer to the exhibits.
A storage network engineer activates a zoneset on MDS-A and verifies the successful activation (Exhibit 1). The engineer is then notified that there is a SAN outage (Exhibit 2) What is the cause of the outage?
A. Another network engineer activated zoneset ZoneSetMDS-B-VSAN100 on MDS-A.
B. Another network engineer issued the zone mode enhanced vsan 100 command on another switch in the fabric.
C. Another network engineer activated the zoneset ZoneSetMDS-B-VSAN100 command on another switch in the fabric.
D. Another network engineer issued the zone default-zone permit vsan 100 command on another switch in the fabric.
Refer to the exhibit.
A user who is logged in as an operator cannot update the zoneset. What is the cause of this issue?
A. The fabric is locked by admin on switch-2.
B. Hard zoning is enabled.
C. Merge control is disabled.
D. The switch has a conflicting domain ID.
E. The fabric is locked by admin on another switch.
Two stable fabrics have overlapping domains. After a switch from the first domain is joined to a switch from the second domain, both switches become isolated. What caused the problem?
A. The autoreconfigure option is disabled on both switches.
B. The autoreconfigure option is enabled on both switches.
C. The rcf-reject option is enabled on the interfaces.
D. The rcf-reject option is disabled on the interfaces.
