Correct Answer: E

PX BLOCK ITERATOR This operation is typically the first step in a parallel pipeline. The BLOCK ITERATOR breaks up the table into chunks that are processed by

each of the parallel servers involved.

Incorrect:

B, C: The scan on the Departsments table is done in parallel.

Note:

* As per exhibit: Line 7 is run first, followed by line 6.

*

Example with same structure of execution plan:

Here's how to read the plan:

1.

The first thing done is at line 9 an index fast full scan on SYS.OBJ$.I_OBJ1 index. This is done in parallel, as indicated from the "PX SEND" line above.

2.

In line 8, we're doing a "PX SEND BROADCAST" operation. When joining tables in parallel, Oracle can choose to either broadcast results (rows) from one operation to apply to the other table scan, or it can choose PX SEND HASH. In this case, our CBO determined that a BROADCOAST was appropriate because the results from the OBJ$ table were much lower than the MYOBJ table

3.

Line 7, the PX RECEIVE step, is basically the consumer of the broadcasted rows in step 8

4.

Line 6 is an in-memory BUFFER SORT of the rows returned from the index scan on OBJ$

5.

Lines 11 and 10, respectively, indicate the full scan and PX BOCK ITERATOR operation for the granules involved in the 8 PQ servers

6.

In line 5, Oracle is doing a hash join on the resulting rows from the parallel scans on MYOBJ and OBJ$

7.

Line 4 is a per-PQ server sort of data from the joind PQ servers

8.

Line 3 is the consumer QC that holds the result of the each of the PQ servers

9.

Line 2 is the PX Coordinator (QC) collecting, or consuming the rows of the joined data

10.

Line 1 is the final SORT AGGREGATE line that performs the grouping function

Correct Answer: AC

*

PARALLEL (AUTO): The database computes the degree of parallelism (C), which can be 1 or greater (not D). If the computed degree of parallelism is 1, then the statement runs serially.

*

You can use the PARALLEL hint to force parallelism. It takes an optional parameter: the DOP at which the statement should run. In addition, theNO_PARALLEL hint overrides a PARALLEL parameter in the DDL that created or altered the table.

The following example illustrates computing the DOP the statement should use: SELECT /*+ parallel(auto) */ ename, dname FROM emp e, dept d

WHERE e.deptno=d.deptno;

* When the parameter PARALLEL_DEGREE_POLICY is set to AUTO, Oracle Database auto- matically decides if a statement should execute in parallel or not and what DOP it should use. Oracle Database also determines if the statement can be executed immediately or if it is queued until more system resources are available. Finally, Oracle Database decides if the statement can take advantage of the aggregated cluster memory or not.

Correct Answer: CD

The first executed join is in line 6. The second executed join is in line 1.

Incorrect:

A: Line 7 and 8 are executed first.

Correct Answer: A

As per exhibit:

Line 7 and line 11 are run in parallel.

Line 8 and line 12 are run in parallel.

Line 9 and line 13 are run in parallel.

Line 10 and line 14 are run in parallel.

Line 6 is a PCWP (parallel combined with parent) and the parent is a P-> P (Parallel to parallel) operation.

Correct Answer: ADFG

Oracle Database prunes partitions when you use range, LIKE, equality (A, F), and IN-list (D) predicates on the range or list partitioning columns, and when you use equality (G) and IN-list predicates on the hash partitioning columns.

Reference: Oracle Database VLDB and Partitioning Guide 11g, Information that can be Used for Partition Pruning
